Warnings
Market demand for this product has caused an extension in leadtimes. Delivery dates may fluctuate. Product exempt from discounts.
Product details
| Power Supply Applications:
ITE
|
| Input Ratio:
4:1
|
| Output Power Max:
54W
|
| No. of Outputs:
1 Output
|
| Output Voltage - Output 1:
12V
|
| Output Current - Output 1:
4.5A
|
| Output Voltage - Output 2:
-
|
| Output Current - Output 2:
-
|
| Output Regulation:
-
|
| Isolation Voltage:
2.25kV
|
| DC / DC Converter Type:
Sixteenth Brick
|
| Input Voltage DC Nom:
48V
|
| DC / DC Converter Output Type:
Fixed, Adjustable
|
| Width:
22.9mm
|
| Height:
9.14mm
|
| Depth:
33mm
|
| Input Voltage DC Min:
18V
|
| Input Voltage DC Max:
75V
|
| Product Range:
UWS Series
|
Other details
| Brand |
MURATA POWER SOLUTIONS |
| Part Number |
UWS-12/4.5-Q48N-C |
| Quantity |
Each |
| Technical Data Sheet EN |
 |
