Product details
| Power Supply Applications:
Gate Drive
|
| Input Ratio:
1:1
|
| Output Power Max:
2W
|
| No. of Outputs:
2 Output
|
| Output Voltage - Output 1:
18V
|
| Output Current - Output 1:
80mA
|
| Output Voltage - Output 2:
-2.5V
|
| Output Current - Output 2:
80mA
|
| Output Regulation:
Unregulated
|
| Isolation Voltage:
5.2kV
|
| DC / DC Converter Type:
SIP
|
| Input Voltage DC Nom:
15V
|
| DC / DC Converter Output Type:
Fixed
|
| Width:
9.8mm
|
| Height:
12.5mm
|
| Depth:
19.5mm
|
| Input Voltage DC Min:
13.5V
|
| Input Voltage DC Max:
16.5V
|
| Product Range:
MGJ Series
|
Other details
| Brand |
MURATA POWER SOLUTIONS |
| Part Number |
MGJ2D151802SC |
| Quantity |
Each |
| Technical Data Sheet EN |
 |
