Description
This is a Isolated Board Mount DC/DC Converter, 2 Output, 750 mW, 15 V, 25 mA, -15 V, -25 mA product from MURATA POWER SOLUTIONS with the model number CMR0515S3C
Product details
| No. of Outputs | 2 Output |
| Output Power Max | 750mW |
| Output Voltage - Output 1 | 15V |
| Output Current - Output 1 | 25mA |
| Output Voltage - Output 2 | -15V |
| Output Current - Output 2 | -25mA |
| Output Voltage - Output 3 | - |
| Output Current - Output 3 | - |
| Product Range | CMR Series |
| Input Voltage DC Min | 4.5V |
| Input Voltage DC Max | 5.5V |
| DC / DC Converter Output Type | Fixed |
| DC / DC Converter Type | SIP |
| DC / DC Converter Mounting | Through Hole |
| Approvals & Standards | - |
| Width | 6mm |
| Height | 10mm |
| Depth | 19.5mm |
Other details
| Brand | MURATA POWER SOLUTIONS |
| Part Number | CMR0515S3C |
| Quantity | Each |
| Technical Data Sheet EN |  |
| Product Change Notice EN | |
