Description
The 78601/3C is a 200µH general purpose low-profile Pulse Transformer with matte tin finish industry standard pin-outs and toroidal-style construction. This 786 series transformer is fully encapsulated and rated with 200µH minimum primary inductance and 1kVrms isolation voltage. The materials used for this transformer are mates with UL94V-0 standards. This comprehensive range transformer is common used in line coupling, matching or isolating. The device can also be used in small isolated power supplies and also as common-mode chokes in filtering applications.
- 14pF Interwinding capacitance
- 300°C for 10 seconds Peak wave solder temperature
Applications
Power Management
Product details
| DC Resistance | 0.25ohm |
| Turns Ratio | 1:1 |
| Product Range | 786 Series |
| Inductance | 200µH |
| Isolation Voltage | 1kV |
| ET Constant | 6Vµs |
Other details
| Brand | MURATA POWER SOLUTIONS |
| Part Number | 78601/3C |
| Quantity | Each |
| Technical Data Sheet EN |  |
| Product Change Notice EN | |
