Description
The RBM3-10RBVR from Multicomp is a 3 x 3, 10 steps flat-head actuator with SMT mounting. The actuator has non switching rating of 24VDC, 400mA and switching rating of 24VDC, 150mA.
- 10,000 steps life and maximum operating force is 400gf.cm
- Initial contact resistance is 100mohm
- Dielectric strength is 250VAC
- Insulation resistance is 100Mohm
- Operating temperature is -60°C to +125°C
- Rotating actuation
- Thermoplastic nylon UL94V-0 base, actuator, cover material
- Brass with gold plated terminal
- Multicomp products are rated 4.6 out of 5 stars
- 12 month limited warranty *view Terms & Conditions for details
- 96% of customers would recommend to a friend
Industrial
Other details
| Brand | MULTICOMP |
| Part Number | RBM3-10RBVR |
| Quantity | Each (Supplied on Cut Tape) |
| Technical Data Sheet EN |  |
