- 12V, IP67 rated constant voltage LED driver
- Fully approved to all lighting specifications, output constant voltage
- High efficiency up to 86%, built-in active PFC function
- ErP compliant, short circuit/ overloading/overtemperature/ overvoltage protection
- Cooling by free air convection, IP67 design for outdoor installation
- Input surge protection: 2KV line-line, low noise and ripple
- 5 years warranty, high efficiency for longer life, size is 148mm � 42mm � 33mm
- 3.34A output current, 40W rated power
- Input voltage range from 220VAC to 240VAC, no load power consumption of <=0.5W
- Safety standards are EN61347-1, EN61347-2-13
Product details
Power Supply Applications |
LED Lighting |
Output Power Max |
40W |
Output Voltage Max |
12V |
Output Current |
3.34A |
LED Driver Mode |
Constant Voltage |
Input Voltage Min |
220VAC |
Input Voltage Max |
240VAC |
Product Range |
- |
Other details
Brand |
MULTICOMP PRO |
Part Number |
MP011863 |
Quantity |
Each |
Technical Data Sheet EN |
|
