Description
MSolutions MS6U41A Overview
Extend the connectivity of your commercially designed equipment such as cameras, drives, and other equipment with the MSolutions MS-6U41A 5-Input Extender Set. Consisting of two parts, this set allows you to connect devices over long distances up to 328 feet via Cat x cable with data transfer speeds up to 320 Mb/s. You get one USB-C port, four USB-A ports, and 2-channel audio jacks, giving you support for a wide range of audio and video devices such as cameras, printers, scanners, and more. RS-232 serial passthrough and 12V Power over Cable (PoC) expands the utility of this device, enabling additional usage for commercial environments. The Micro-USB port allows you to upgrade the firmware of the device to keep it up to date with various improvements. Included surface mounting brackets allow you to affix each component to various tables, desks, and more, for an organized and safe workspace.
In the Box
- MSolutions MS-6U41A 5-Input Extender Set
- 12V 2A Power Supply
- 2 x Surface Mounting Brackets
- 2 x 3-Pin Phoenix Connector Blocks
- USB-C to USB-A Female Cable
- USB-C Cable
- Limited 3-Year Manufacturer Warranty
MSolutions MS6U41A Specs
| Maximum Range |
328.1' / 100 m
|
| Receiver I/O |
1x Micro-USB Input
1x RJ45 (Ethernet) Input 1x USB-C Output 4x USB-A Input 1x 1/8" / 3.5 mm (Audio) Input 1x 1/8" / 3.5 mm (Audio) Output 1x Block 3-Pin (RS-232) Input |
| Transmitter I/O |
1x Micro-USB Input
1x RJ45 (Ethernet) Output 1x USB-C Output 1x 1/8" / 3.5 mm (Audio) Input 1x 1/8" / 3.5 mm (Audio) Output 1x Block 3-Pin (RS-232) Output |
| Power Source |
Power Adapter
|
| Receiver I/O |
1x Micro-USB Input
1x RJ45 (Ethernet) Input 1x USB-C Output 4x USB-A Input 1x 1/8" / 3.5 mm (Audio) Input 1x 1/8" / 3.5 mm (Audio) Output 1x Block 3-Pin (RS-232) Input |
| Transmitter I/O |
1x Micro-USB Input
1x RJ45 (Ethernet) Output 1x USB-C Output 1x 1/8" / 3.5 mm (Audio) Input 1x 1/8" / 3.5 mm (Audio) Output 1x Block 3-Pin (RS-232) Output |
| Power Source |
Power Adapter
|
| Power Connector |
Unspecified Size Barrel
|
| DC Input Power |
12 VDC at 2 A
|
| Operating Humidity |
0 to 80% ()
|
| Operating Temperature |
32 to 72°F / 0 to 40°C
|
| Storage Temperature |
-4 to 140°F / -20 to 60°C
|
| Dimensions |
2.4 x 1.0 x 3.3" / 6.0 x 2.5 x 8.4 cm Each
|
| Weight |
Each: 0.4 lb / 200 g
|
| Package Weight |
1.17 lb
|
| Box Dimensions (LxWxH) |
6.6 x 6.4 x 3.4"
|
