Description
MSolutions MS-3PRI Overview
Use the MS-3PRI HDBaseT Extender Set with Single-Channel 5V IR by MSolutions to extend uncompressed HDMI video over HDBaseT. This unit handles video at 4K at 60 Hz and 4:4:4. Extend 4K video up to 295.2', and 1080p or lower resolution video up to 328' all on one Cat cable. Additional connectivity includes a bidirectional RS-232 via an integrated 3-pin Phoenix connector with the block included and a single-channel IR port supporting TX to RX and RX to TX. The extender set handles all known HDMI audio formats, including Dolby Atmos and DTS:X, is HDCP 2.2 compliant and has a Consumer Electronics Control (CEC) pass-through. Power the setup with the included bidirectional 12V Power over Cable adapter.
Items Included
- MSolutions MS-3PRI HDBaseT Extender Set with Single-Channel 5V IR
- 12 VDC, 2A Power Supply with US, UK & EU Clips
- RS-232 Phoenix Connector
- IR Receiver (5V) with 3' Cable
- IR Transmitter (5V) with 3' Cable
- 2 x 3-Pin Phoenix Connectors
- 2 x Surface Mounting Brackets
- Limited 1-Year Manufacturer Warranty
Additional Resources
MSolutions MS-3PRI Specs
| Inputs |
1x HDMI (HDMI 2.0)
|
| Embedded Audio Input |
HDMI
|
| Outputs |
1x RJ45 (HDBaseT)
|
| Transmitter Other I/O |
1x 1/8" / 3.5 mm IR Input/Output
1x Block 3-Pin RS-232 |
| Inputs |
1x RJ45 (HDBaseT)
|
| Outputs |
1x HDMI (HDMI 2.0)
|
| Embedded Audio Output |
HDMI
|
| Receiver Other I/O |
1x 1/8" / 3.5 mm IR Input/Output
1x Block 3-Pin RS-232 |
| HDR Support |
Yes: HDR10
|
| HDCP Support |
Yes: Version 2.2
|
| Max Transmission Distance |
DCI 4K at 60 Hz:
295.3' / 90 m |
| Video Format |
HDMI (4:4:4):
4096 x 2160: 59.94 fps 1920 x 1080p: 59.94 fps |
| Audio Format |
Unspecified Digital Signal
|
| Surround/Immersive Audio |
DTS:X, Dolby Atmos
|
| Supported Cable Types |
Cat 5e or higher
|
| Transmitter Power I/O |
1x Barrel (12 VDC at 2 A) Input
|
| Receiver Power I/O |
1x Barrel (12 VDC at 2 A) Input
|
| PoE Support |
PoE Proprietary
|
| Transmitter Power Consumption |
(13 W)
|
| Receiver Power Consumption |
(13 W)
|
| Certifications |
CE, FCC, RoHS, WEEE
|
| Operating Conditions |
32 to 104?F / 0 to 40?C up to 80% Humidity
|
| Storage Conditions |
-4 to 140?F / -20 to 60?C
|
| Transmitter Dimensions |
3.3 x 2.4 x 1" / 84 x 60 x 25 mm
|
| Receiver Dimensions |
3.3 x 2.4 x 1" / 84 x 60 x 25 mm
|
| Transmitter Weight |
3.5 oz / 0.1 kg
|
| Receiver Weight |
3.5 oz / 0.1 kg
|
| Package Weight |
1.255 lb
|
| Box Dimensions (LxWxH) |
6.5 x 5.8 x 3.4"
|
