- Primary side control offline LED controller with active PFC, NTC, PWM dimming in TSOT23-8 package
- Real current control without secondary feedback circuit
- <2% line/load regulation
- NTC thermal current fold-back
- High PF (>=0.9) over universal input voltage
- Valley switching mode for improved efficiency
- Brown-out protection, overvoltage protection and short circuit protection
- Overtemperature protection, primary side overcurrent protection
- Cycle-by-cycle current limit, VCC undervoltage lockout protection
- Auto-restart function
Product details
| Device Topology |
Buck-Boost, Flyback |
| Input Voltage Min |
12V |
| Input Voltage Max |
28V |
| Output Voltage Max |
- |
| Output Current Max |
- |
| Switching Frequency |
- |
| No. of Outputs |
1Outputs |
| IC Mounting |
SMD |
| Driver Case Style |
TSOT-23 |
| No. of Pins |
8Pins |
| Operating Temperature Min |
-40°C |
| Operating Temperature Max |
125°C |
| Product Range |
- |
| Automotive Qualification Standard |
- |
Other details
| Brand |
MONOLITHIC POWER SYSTEMS (MPS) |
| Part Number |
MP4027GJ-P |
| Quantity |
Each (Supplied on Cut Tape) |
| Technical Data Sheet EN |
 |
