Description
The 505605-1000 from Molex is a 505605 series 3.30mm pitch, dual row, polarized, CP-3.3 receptacle housing with 10 circuits. Ensures complete, low-insertion-force locking and provides a tactile and audible 'click' when mated. It mates with 505606-1000 plug housing.
- Natural colour PBT resin, UL94-V0 flammability rating
- Operating temperature range from -40°C to +105°C
- Fully polarized housings prevents accidental mismating
- Full keying and colour-pairing features
- For use with 504695 terminal retainer and 50397, 505607 receptacle crimp terminal
Consumer Electronics, Industrial, Industrial Automation, Medical
Other details
| Brand | MOLEX |
| Part Number | 505605-1000 |
| Quantity | Each |
| Technical Data Sheet EN |  |
| Drawing EN | |
