Description
The 502351-0800 is a 8-way 1-row DuraClik� wire-to-board female Receptacle Housing suitable for signal application. It mates with 560020 and 502352 2.00mm pitch DuraClik� wire-to-board header. This 47725 series receptacle housing can be used with 560085 DuraClik� crimp terminal for 22 to 26AWG, 50212 2.00mm pitch crimp terminal for 24 to 30AWG, 56161 2.00mm pitch crimp terminal for 22 to 26AWG. Molex part has an inner-locking system versus an outer-locking system. Molex part with tail protection feature.
- 3A Maximum current per contact
Applications
Automotive, Commercial, Industrial, Automation & Process Control
Product details
| Gender | Receptacle |
| No. of Positions | 8Ways |
| Product Range | DuraClik Series |
| For Use With | 50212, 560085, 56161 Series Female Crimp Terminals |
| Pitch Spacing | 2mm |
Other details
| Brand | MOLEX |
| Part Number | 502351-0800 |
| Quantity | Each |
| Technical Data Sheet EN |  |
| Drawing EN | |
| 3D Product Image EN | |
| Product Change Notice EN | |
