Description
The 43045-1219 from Molex is a Micro-Fit 3.0, 3.00mm pitch, dual row, 12 circuits vertical wire to board PCB header with solder tab. It mates with 43025 Micro-Fit 3.0 receptacle housing.
- Tin plated copper contact
- Flammability rating is 94V-0
- Durability (mating cycles max) is 30
- Operating temperature range from -40�C to +105�C
- Surface mount termination
- Current rating is 5.0A
- Voltage rating is 600V
- Fully shrouded
- UL E29179 recognized and CSA LR19980 certified
Applications
Industrial
Product details
| No. of Rows | 2Rows |
| Contact Material | Brass Alloy |
| Contact Plating | Gold Plated Contacts |
| Pitch Spacing | 3mm |
| Contact Termination Type | Surface Mount |
| No. of Contacts | 12Contacts |
| Product Range | Micro-Fit 3.0 43045 Series |
| Gender | Header |
Other details
| Brand | MOLEX |
| Part Number | 43045-1219 |
| Quantity | Each (Supplied on Cut Tape) |
| Technical Data Sheet EN |  |
| Product Change Notice EN | |
