| ₹ 66.42 includes GST and import duties. | |
| B2B customers can avail ₹ 10.13 ITC on this product | |
| 100% Secure Payments | 100% Genuine product |
Description
The 22-01-3077 is a 7-way 1-row KK® 254 female crimp housing made of nylon with friction ramp. It mates with 42375, 42377, 42376, 4030, 6373 and 6410 KK®254 PCB headers. The crimp housing is suitable for signal and wire-to-board applications. This 2695 series receptacle housing can be used with 2759 and 4809 KK® crimp terminals.
- Natural (white) colour
- UL94V-0 flammability rating
- Lock to mating part
- Polarized to mating part
Automotive, Communications & Networking, Consumer Electronics, Medical
Other details
| Brand | MOLEX |
| Part Number | 22-01-3077 |
| Quantity | Each |
| Technical Data Sheet EN |  |
| Product Change Notice EN | |
| Drawing EN | |
| 3D Product Image EN | |
| CAD Multiple Formats EN | |
All product and company names are trademarks™ or registered® trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them. Image is for illustrative purposes only. Please refer to product description.
Bulk Discount
| Quantity | Price |
| 2 | ₹ 65.09 |
| 3-5 | ₹ 64.43 |
| 5-10 | ₹ 63.1 |
| 10+ | ₹ 61.77 |
Bulk discount will be automatically applied during checkout based on quantity.
