173111-0064 is a FCT plastic backshell with large inner chamber for use with size 3 D-sub connector.
- UL recognized/listed under file no. E197631
- Large inner chamber, suitable for D-Sub connectors with special contacts
- 45° angle large diameter cable outlet
- with rubber bushing and 4-40 UNC locking screws
- Easy assembly with catch spring system and premounted locking screws
- Zinc die-cast material and steel screw
- Operating temperature range from -35° to +100°C
- Cable diameter range from 12.0 to 15.0mm
Product details
| Product Range:
173111
|
| D Sub Shell Size:
DD
|
| Cable Exit Angle:
45°
|
| Connector Body Material:
Zinc Body
|
Other details
| Brand |
MOLEX |
| Part Number |
173111-0064 |
| Quantity |
Each |
| Technical Data Sheet EN |
 |
