Molex 172249-0100 172249-0100 PCB Terminal Brass 1.1 mm Tin Solderright 172249

The 172249-0100 is a SolderRight� male right angle direct solder In-line Mount Terminal made of brass with matte tin plated finish. This 172249 series terminal accepts 16 to 14AWG wire. It mates with solder straight to PCB. The SolderRight� direct-solder terminal is ideal for tight packaging constraints, low-profile terminal enable right-angle connections onto a PCB at a low applied cost. From laptop computers to handheld devices, electronic systems, products and packaging are becoming exponentially smaller. Until now, users were forced to either solder a bare wire into a PCB or bend it over (resulting in poor reliability and a higher-profile termination) or use a two-piece connector system. SolderRight� crimp terminals solve both of these issues. With an industry need for low-profile packaging, reduced wire connections, permanently connected circuits and higher standards of reliability, these are the only board-in crimp solder options in the market that address all of these points.

• Right-angle mounting orientation
• Enable signal-to-power current capability while optimizing PCB space
• One of the most reliable, direct solder interconnects in the market
• Allows minimum "z" height soldering profile for tight packaging constraints
• Maximum current per contact is 14A

Applications

Industrial

Other details

Brand	MOLEX
Part Number	172249-0100
Quantity	Each (Supplied on Cut Tape)
