Miller ArrowX 3 Tripod System Overview
-
1Description
-
2Lightweight Versatility
-
3Quick Setup and Accurate Performance
-
4CB Plus Counterbalance System
-
5Fluid Pan and Tilt Drag
-
6Accessible Controls
-
73-Stage Carbon Fiber Tripod
-
8Locking Leg Positions
-
9Quick Setup
The 100mm ball Arrowx 3 2520 Solo-Q 100 3-Stage Tripod System from Miller combines the Arrowx 3 video fluid head with the carbon fiber Solo-Q carbon fiber tripod. Perfect for fast-paced ENG and documentary production, this system offers stable, rigid support for camera rigs weighing from 2.2 to 41.9 lb. This versatile payload capacity and a height range of 15.4 to 80.4" makes this system compatible with a wide range of cameras and lenses, negating the need to bring two tripods on your shoot to accommodate smaller and larger cameras.
The Arrowx 3 head features the 16-step CB Plus counterbalance system, with full and half stops, a sliding balance plate, centrally located controls and illuminated bubble level, and five steps of fluid pan and drag plus a zero setting for free spins and safe transport or storage. The 3-stage tripod features carbon fiber construction, quick-lock legs, and three leg positions with a safety lock feature, eliminating the need for a spreader.
Lightweight Versatility
Compact and lightweight, this Arrowx 3 system supports up to 41.8 lb but weighs just 15.2 in total
Quick Setup and Accurate Performance
Rapid leg extension and smooth pan, tilt, and counterbalancing are ideal for ENG and documentary production
CB Plus Counterbalance System
The 16-step CB Plus system offers precise counterbalance performance over the entire payload and temperature ranges
Fluid Pan and Tilt Drag
Select from five pan and tilt drag levels to best suit your move and rig weight, or choose "0" for free spins and safe travel or storage
Accessible Controls
Pan/tilt drag controls, counterbalance settings, and an illuminated bubble level are clustered together for quick adjustments
3-Stage Carbon Fiber Tripod
Lightweight yet strong carbon fiber tripod with three extendable stages
Locking Leg Positions
Three locking leg angles enable you to safely position the tripod without requiring a spreader
Quick Setup
Rapid-lock legs enable you to quickly set up and adjust your tripod position
In the Box
- Miller Arrowx 3 2520 Solo-Q 100 3-Stage Carbon Fiber Tripod System (100mm)
- Miller Arrowx 3 Fluid Head
- Miller Solo-Q 100 3-Stage Carbon Fiber Tripod
- Miller Arrowx softcase 2 Stage for Sprinter II and Toggle 2 Stage Tripod Systems (Black)
- Limited 3-Year Warranty
Table of Contents
- Description
- Lightweight Versatility
- Quick Setup and Accurate Performance
- CB Plus Counterbalance System
- Fluid Pan and Tilt Drag
- Accessible Controls
- 3-Stage Carbon Fiber Tripod
- Locking Leg Positions
- Quick Setup
Miller ArrowX 3 Tripod System Specs
Camera Plate
| Camera Plate Features |
Quick Release, Sliding Balance Plate |
| Camera Mounting Screw |
1 x 1/4"-20 Male
1 x 3/8"-16 Male |
| Balance Plate Sliding Range |
4.7" / 120 mm |
| Safety Lock |
Yes |
Head
| Base Mount |
100 mm Half Ball |
| Camera Platform Adjustment |
Yes, (4.7" / 120.0 mm) |
| Counter Balance |
Incremental 16-Step |
| Pan Handle Fittings |
2 x Rosette |
| Included Pan Handle Length |
15.4 to 23.2" / 390 to 590 mm |
| Bubble Level |
1 x Illuminated |
Pan & Tilt
| Drag Control |
Tilt: 5-Step Plus 0
Pan: 5-Step Plus 0 |
| Drag Type |
Fluid |
| Vertical Tilt |
+90° to -75° |
| Panning Range |
360° |
| Independent Pan Lock |
Yes |
| Independent Tilt Lock |
Yes |
Legs
| Leg Lock Type |
Twist Lock |
| Leg Positions |
3 Positions |
| Independent Leg Spread |
Yes |
| Leg Sections |
4 |
| Spreader |
None |
General
| Load Capacity |
2.2 to 41.8 lb / 1 to 19 kg |
| Maximum Working Height |
80.4" / 204.1 cm |
| Minimum Working Height |
15.4" / 39 cm |
| Folded Length |
32.5" / 82.5 cm |
| Materials |
Carbon Fiber |
| Operating Temperature |
-40 to 149°F / -40 to 65°C |
| Weight |
15.2 lb / 6.9 kg |
Packaging Info
| Package Weight |
33.55 lb |
| Box Dimensions (LxWxH) |
39.38 x 14.63 x 13" |
