Description
64Mbit, 2.5V/3V, SQI� flash memory features a six-wire, 4bit I/O interface that allows for low power, high performance operation in a low pin count package.
- Nibble-wide multiplexed I/O's with SPI-like serial command structure
- High speed clock frequency (2.7-3.6V: 104MHz max/2.3-3.6V: 80MHz max)
- Continuous linear burst and 8/16/32/64byte linear burst with wrap-around
- Superior reliability, low power consumption, fast erase time and 256bytes per page in x1 or x4 mode
- Software polling the BUSY bit in status register
- Flexible erase capability (uniform 4KByte sectors, uniform 64Kbyte overlay blocks)
- Suspend program or erase operation to access another block/sector
- Software Reset (RST) mode, software protection, security ID (user-programmable area)
Warnings
Market demand for this product has caused an extension in leadtimes. Delivery dates may fluctuate. Product exempt from discounts.
Product details
| Flash Memory Type: Serial NOR |
| Memory Density: 64Mbit |
| Memory Configuration: 8M x 8bit |
| Interfaces: SPI, SDI, SQI |
| IC Case / Package: WDFN |
| No. of Pins: 8Pins |
| Clock Frequency Max: 104MHz |
| Access Time: - |
| Supply Voltage Min: 2.3V |
| Supply Voltage Max: 3.6V |
| Supply Voltage Nom: 3.3V |
| IC Mounting: Surface Mount |
| Operating Temperature Min: -40°C |
| Operating Temperature Max: 85°C |
| Product Range: 3V Serial NOR Flash Memories |
| MSL: MSL 1 - Unlimited |
Other details
| Brand | MICROCHIP |
| Part Number | SST26VF064B-104I/MN |
| Quantity | Each |
| Technical Data Sheet EN |  |
