Description
SMART� ARM-based microcontroller with ARM Cortex-M0+ CPU running at up to 48MHz.
- Power-on reset (POR) and brown-out detection (BOD), External Interrupt Controller (EIC)
- One non-maskable interrupt and 16 external interrupts
- SleepWalking peripherals, idle and standby sleep modes
- 8 event system channels and 8 timer counter (TC)
- 2 waveform output channels for TC and 6 serial communication interface (SERCOM)
- 20 ADC, 1 DAC and 2 analogue comparators
- Real-Time Counter (RTC) and RTC alarms
- 16 external interrupt lines and SW debug interface
- 16 x 16 Peripheral Touch Controller (PTC) X and Y lines
- Watchdog timer (WDT)
Warnings
Market demand for this product has caused an extension in leadtimes. Delivery dates may fluctuate. Product exempt from discounts.
Product details
| Product Range: SAM32 Family SAM D2X Series Microcontrollers |
| Device Core: ARM Cortex-M0+ |
| Data Bus Width: 32 bit |
| Operating Frequency Max: 48MHz |
| Program Memory Size: 256KB |
| No. of Pins: 64Pins |
| IC Case / Package: TQFP |
| No. of I/O's: 52I/O's |
| Interfaces: I2C, SPI, UART, USART |
| RAM Memory Size: 32KB |
| ADC Channels: 20Channels |
| ADC Resolution: 12Bit |
| Supply Voltage Min: 1.62V |
| Supply Voltage Max: 3.63V |
| Operating Temperature Min: -40°C |
| Operating Temperature Max: 105°C |
| IC Mounting: Surface Mount |
| MCU Family: SAM32 |
| MCU Series: SAM D2X |
| Qualification: - |
| MSL: MSL 3 - 168 hours |
Other details
| Brand | MICROCHIP |
| Part Number | ATSAMD20J18A-AN |
| Quantity | Each |
| Technical Data Sheet EN |  |
