HLG-80H-12A is a HLG-80H series AC/DC LED driver featuring the dual mode constant voltage and constant current output. HLG-80H operates from 90�305VAC. Thanks to the high efficiency up to 91%, with the fanless design, the entire series is able to operate for -40� ~ +80� case temperature under free air convection. The design of metal housing and ingress protection level allows this series to fit both indoor and outdoor applications. HLG-80H is equipped with various function options, such as dimming methodologies, so as to provide the optimal design flexibility for LED lighting system. Typical applications are LED street lighting, LED high-bay lighting, parking space lighting, LED fishing lamp, LED greenhouse lighting, Type �HL� for use in class I , Division 2 hazardous (Classified) location.
- Metal housing with class I design, cable output
- Built-in active PFC function, single output
- Class 2 power unit, analogue potentiometer dimming technology
- IP65 rating for indoor or outdoor installations
- Typical lifetime is 62000hours
- Rated wattage is 80W
- Input voltage is 110/230V universal input, 90 - 305V
- Output current is 5A, 12V output voltage
- 7 years warranty
- Dimension is 61.5mm width x 38.8mm height x 195.6mm depth
Product details
| Power Supply Applications:
LED Lighting
|
| Output Power Max:
60W
|
| Output Voltage Max:
13.5V
|
| Output Current:
5A
|
| LED Driver Mode:
Constant Current, Constant Voltage
|
| Input Voltage Min:
90VAC
|
| Input Voltage Max:
305VAC
|
| Product Range:
HLG-80H Series
|
Other details
| Brand |
MEAN WELL |
| Part Number |
HLG-80H-12A |
| Quantity |
Each |
| Technical Data Sheet EN |
 |
