Description
McDSP APB-8 Overview
The McDSP APB-8 is an 8-channel programmable analog processor that seamlessly integrates the sonic richness of analog hardware with the convenience of digital workflows. It allows users to insert APB plug-ins into their DAW sessions just like standard plug-ins. However, instead of processing audio digitally, these plug-ins send control signals to the APB-8 hardware, which processes the audio in the analog domain before converting it back to digital and returning it to the DAW at audio resolutions up to 32-Bit/192 kHz. Up to eight mono APB plug-ins or up to four stereo APB plug-ins can run on a single APB-8. A growing collection of APB plug-ins is included, no additional purchases necessary.
The APB-8 comes with two USB-C style connectors that support Thunderbolt 3 and Thunderbolt 4 ports on both Intel and Apple silicon Macs�operating at twice the bandwidth of the original APB units that came with Thunderbolt 2. It is compatible with major DAWs like Pro Tools, Logic Pro, and Cubase through AAX, AU, and VST3 plug-in formats. McDSP APB plug-ins are not compatible with Windows, nor do they support the VENUE S6L systems. APB plug-ins require an iLok2 or iLok3 USB Smart Key, or an iLok License Manager account and an iLok Cloud session for authorization.
- TAPE Analog Tape Machine Emulation
- BOB Bass Optimized Bias
- KD1 Kinetic Drive
- Royal Mu Compressor and Limiter
- Royal Mu Surround Compressor and Limiter
- Royal Q Equalizer
- MC-3 Multi-band Compressor
- Moo X Mixer
- C673-A Dynamic Range Compressor
- EL MOO Tube Limiter
- MOO TUBE Compressor
- ChickenHead Compressor
- L-18 Limiter
- L-18 Surround Limiter
- C-18 Compressor
Items Included
- McDSP APB-8 8-Channel Analog Processing Box with Thunderbolt 3
- Power Supply
- Limited 1-Year Manufacturer Warranty
Additional Resources
No additional resources available
McDSP APB-8 Specs
| Form Factor |
Rackmount
|
| Display |
No
|
| Channels of I/O |
8 Input / 8 Output
|
| Built-In DSP |
Yes
|
| Maximum Sampling Rate |
192 kHz / 32-Bit
|
| Number of Microphone Inputs |
No Mic Inputs
|
| Built-In Microphone |
No
|
| Pad |
No
|
| Solo/Mute |
No
|
| Analog Audio I/O |
No
|
| Phantom Power |
No
|
| Digital Audio I/O |
No
|
| Host Connection |
2x USB-C
|
| Host Connection Protocol |
Thunderbolt 3
|
| USB (Non-Host) |
No
|
| Sync I/O |
1x BNC Word Clock Input
1x BNC Word Clock Output |
| Network I/O |
No
|
| MIDI I/O |
No
|
| Expansion Slots |
No
|
| Wireless |
No
|
| Sample Rates |
44.1 / 48 / 88.2 / 96 / 176.4 / 192 kHz
|
| Bit Depths |
32-Bit
|
| Sync Sources |
Word Clock
|
| Media/Memory Card Slot |
No
|
| OS Compatibility |
macOS 10.13 or Later
|
| Mobile Device Compatibility |
No
|
| Required Hardware |
Thunderbolt 3 Port
|
| Power Requirements |
AC/DC Power Adapter (Included)
|
| AC/DC Power Adapter |
18 VDC (Included)
|
| Rackmount Size |
1 U (with Non-Included Hardware)
|
| Package Weight |
16.34 lb
|
| Box Dimensions (LxWxH) |
24.3 x 23.7 x 8"
|
