SAC series axial leaded TVS diode designed specifically to protect sensitive electronic equipment from voltage transients induced by lightning and other transient voltage events. It is ideal for the protection of I/O interfaces, VCC bus and other vulnerable circuits used in telecom, computer, industrial and consumer electronic applications.
- Glass passivated chip junction in DO-15 package
- Fast response time: typically less than 1.0ps from 0V to BV min
- Typical failure mode is short from over-specified voltage or current
- Whisker test is conducted based on JEDECJESD201A per its table 4a and 4c
- IEC-61000-4-2 ESD 30KV(Air), 30KV (Contact)
- ESD protection of data lines in accordance with IEC 61000-4-2
- Low incremental surge resistance
- EFT protection of data lines in accordance with IEC 61000- 4-4
- Plastic package is flammability rated V-0 per underwriters laboratories
- Ideal for data line applications
Other details
| Brand |
LITTELFUSE |
| Part Number |
SAC5.0 |
| Quantity |
Each (Supplied on Cut Tape) |
| Technical Data Sheet EN |
 |
