Description
Lilliput Q13-8K Overview
The Q13-8K 13.3" 8K 12G-SDI Studio / Broadcast Monitor from Lilliput features a 13.3" native 3840 x 2160 resolution display with a V-mount battery plate, useful for both studio and field situations. The monitor features one HDMI 2.0 input and four 12G-SDI inputs, allowing for single-, dual-, and quad-link SDI input of up to 8K resolution video. In addition, the monitor supports an optional 12G SFP+ card, so you can display images over fiber on this monitor. The monitor also features loop-through HDMI and 12G-SDI outputs to pass the signal downstream.
Input video signals are automatically scaled to fit the entire 3840 x 2160 screen. Audio embedded in the HDMI and SDI signals play through the monitor's speakers, and a 3.5mm headphone jack allows you to monitor without outside noise. The monitor also supports adjustable HDR color spaces, including HLG, and 3D-LUTs. In the studio, the included power supply allows you to power the monitor from a mains outlet via the 4-pin XLR port, or you can power it from a V-mount battery using the included battery plate. The monitor comes with a mounting bracket for desktop use and a VESA mounting plate for mounting in the field.
- Peaking
- Check field
- Image rotation/flip
- Overscan
- Underscan
- Image freeze
- Pixel-to-pixel
- False color
- Exposure
- Histogram
- Timecode (SDI-only)
- Aspect ratio selection
- Screen markers
- Color space
- HDR
- Color temperature adjustment
Items Included
- Lilliput Q13-8K 13.3" 8K 12G-SDI Studio / Broadcast Monitor (V-Mount)
- Power Adapter
- V-Mount Battery Plate
- Limited 1-Year Manufacturer Warranty
Additional Resources
Lilliput Q13-8K Specs
| Display Size |
13.3" / 33.8 cm
|
| Native Resolution |
3840 x 2160
|
| Touchscreen |
No
|
| HDR Support |
Yes, Hybrid Log Gamma
|
| Video I/O |
4x BNC (12G-SDI) Input
1x HDMI 2.0 Input 4x BNC (12G-SDI) Output 1x HDMI 2.0 Output |
| Media/Memory Card Slot |
No
|
| Video Format |
SDI
8K: 60/50/30/25/24 UHD 4K: 60/50/30/25/24 1080p: 60/50/30/25/24 1080PsF: 30/25/24 1080i: 60/50 HDMI UHD 4K: 60/50/30/25/24 1080p: 60/50/30/25/24 1080i: 60/50 720p: 60/50 Fiber UHD 4K: 60/50/30/25/24 1080p: 60/50/30/25/24 1080PsF: 30/25/24 1080i: 60/50 |
| Built-In Battery |
Yes
|
| Battery Type |
1x V-Mount
|
| Power Consumption |
36 W
|
| Panel Type |
LCD
|
| Display Size |
13.3" / 33.8 cm
|
| Native Resolution |
3840 x 2160
|
| Aspect Ratio |
16:9
|
| Viewing Angle |
Horizontal: 178°
Vertical: 178° |
| Touchscreen |
No
|
| Maximum Brightness |
300 nits / cd/m2
|
| Contrast Ratio |
1000:1
|
| HDR Support |
Yes, Hybrid Log Gamma
|
| Pixels Per Inch (ppi) |
331 ppi
|
| LUT Support |
Yes
|
| Image Controls |
False Color, Focus Peaking, Histogram, Pixel Zoom, Pixel-to-Pixel Zoom, Screen Markers, Vectorscope, Waveform, Zebra
|
| Video I/O |
4x BNC (12G-SDI) Input
1x HDMI 2.0 Input 4x BNC (12G-SDI) Output 1x HDMI 2.0 Output |
| Embedded Audio |
SDI: 16-Channel
HDMI: 8-Channel |
| Audio I/O |
1x 1/8" / 3.5 mm Headphone Output
|
| Built-In Speaker |
Stereo
|
| Power I/O |
1x XLR 4-Pin Input
|
| Other I/O |
1x USB-A (LUT Upload)
1x RJ45 (GPI) Input 1x RJ45 (RS-422) Input 1x RJ45 (RS-422) Output 1x RJ45 (LAN) Input/Output |
| Expansion Slots |
1x SFP+ Slot
|
| Media/Memory Card Slot |
No
|
| Wi-Fi |
No
|
| Bluetooth |
No
|
| Mobile App Compatible |
No
|
| Video Format |
SDI
8K: 60/50/30/25/24 UHD 4K: 60/50/30/25/24 1080p: 60/50/30/25/24 1080PsF: 30/25/24 1080i: 60/50 HDMI UHD 4K: 60/50/30/25/24 1080p: 60/50/30/25/24 1080i: 60/50 720p: 60/50 Fiber UHD 4K: 60/50/30/25/24 1080p: 60/50/30/25/24 1080PsF: 30/25/24 1080i: 60/50 |
| Gamma Curve |
Canon Log, DCI-P3, HDR-HLG, JVC J-Log, Nikon N-Log, Rec709, Sony S-Log 2, Sony S-Log 3, Standard
|
| Input Power |
12 to 24 VDC
|
| Built-In Battery |
Yes
|
| Battery Type |
1x V-Mount
|
| Power Consumption |
36 W
|
| Environmental Resistance |
No
|
| Operating Conditions |
32 to 122°F / 0 to 50°C
|
| Storage Conditions |
-4 to 140°F / -20 to 60°C
|
| Material of Construction |
Metal
|
| Dimensions |
13.4 x 9.2 x 1.8" / 340 x 232.8 x 46 mm
|
| Weight |
5.3 lb / 2.4 kg
|
| Package Weight |
12.205 lb
|
| Box Dimensions (LxWxH) |
17.6 x 15.4 x 7.8"
|
