Description
Lilliput FS5 Overview
Increased picture density and reduced power consumption are just a few of the advantages of the FS5-B 5.4" HDMI 2.0/3G-SDI On-Camera Monitor from Lilliput, an LTPS/LCD monitor for the 4K video shooter who can also benefit from having waveform and vectorscope support at the push of a button. Designed with HDMI and 3G-SDI input and output connectivity, the FS5-B offers 3D-LUT and HDR support and has color space options that include DCI-P3, Rec.709, and FS5.
The monitor handles 1920 x 1200 resolution and is capable of displaying up to 4K60 when using the HDMI input, and 1080p60 when opting for 3G-SDI. Plates for both NP-F and LP-E6 batteries are included and easily interchangeable for quick adaptation to your preferred battery. A ball mount shoe adapter, a protective silicone case that fits around the perimeter of the unit, and a sunshade are also part of the accessories that come with the FS5-B.
In the Box
- Lilliput FS5-B 5.4" HDMI 2.0/3G-SDI On-Camera Monitor
- 12 VDC Power Adapter
- HDMI Type A to Type C Cable (2.6')
- NP-F Battery Plate
- LP-E6 Battery Plate
- Red Silicone Case
- Sunshade
- Hot Shoe Ball Mount
Lilliput FS5 Specs
| Panel Type | LCD |
| Display Size | 5.4" / 13.7 cm |
| Resolution | 1920 x 1200 |
| Aspect Ratio | 16:10 |
| Viewing Angle | Horizontal: 160° Vertical: 160° |
| Touchscreen | No |
| Maximum Brightness | 600 cd/m2 |
| Contrast Ratio | 1100:1 |
| HDR Compatibility | Hybrid Log Gamma |
| Pixels Per Inch (ppi) | 419 ppi |
| Color Gamut | 88% DCI-P3 |
| Image Controls | Check Field, Color Temperature Selection, Customizable Aspect Ratios, False Color, Focus Assist, Focus Peaking, Histogram, Pixel Value Checker, Pixel-to-Pixel Zoom, Vectorscope, Waveform |
| Video I/O | 1 x BNC (3G-SDI) Input 1 x BNC (3G-SDI) Output 1 x HDMI 2.0 Input 1 x HDMI 2.0 Output |
| Audio I/O | 1 x 1/8" / 3.5 mm Headphone Output |
| Built-In Speaker | 1 |
| Power I/O | 1 x Barrel (12 VDC) Input |
| Other I/O | 1 x Mini-USB 2.0 Input |
| Media/Memory Card Slot | None |
| Wi-Fi | None |
| Video Format | SDI 1080p: 60/50/30/25/24 1080PsF: 30/25/24 1080i: 60/50 720p: 60/50/30/25/24 HDMI DCI 4K: 60/50/30/25/24 1080p: 60/50/30/25/24 1080i: 60/50/30/25/24 720p: 60/50/30/25/24 |
| Gamma Curve | ARRI Log C, Canon Log, DCI-P3, JVC J-Log, Panasonic V-Log, Rec709, Sony S-Log 2, Sony S-Log 3 |
| DC Input Power | 7 to 24 VDC |
| Battery Type | 1 x LP-E6, L-Series (Interchangeable Mount) |
| Operating Current | 0.75 A |
| Power Consumption | 9 W |
| Mounting | 1 x 1/4"-20 Female |
| Operating Temperature | 12 to 82°F / -20 to 50°C |
| Storage Temperature | 86 to 158°F / 30 to 70°C |
| Material of Construction | Metal |
| Dimensions | 6.1 x 3.5 x 0.8" / 154.5 x 90 x 20 mm |
| Weight | 10.4 oz / 295 g |
| Package Weight | 2.175 lb |
| Box Dimensions (LxWxH) | 6.9 x 5 x 3.9" |
