Description
Lilliput Q31 Overview
The Lilliput 31.5" 12G-SDI/HDMI Broadcast Studio Monitor is a 31.5" native UHD 4K monitor with a Gold mount battery plate, useful for both studio and field situations. Supporting up to DCI 4K (4096 x 2160) and UHD 4K (3840 x 2160), the monitor features one HDMI 2.0 input and four SDI inputs (two 12G, two 3G), allowing for single-, dual-, and quad-link SDI input. The monitor also features loop-through HDMI and SDI outputs to pass the signal downstream. For critical color work, the monitor supports the PRO/LTE version of LightSpace CMS (not included).
Input video signals are automatically scaled to fit the entire 3840 x 2160 screen. Audio embedded in the HDMI and SDI signals play through the monitor's speakers, and a 3.5mm headphone jack allows you to monitor without outside noise. The monitor also supports adjustable HDR color spaces, including HLG, and you can select from 17 built-in 3D-LUTs or import six of your own. In the studio, the included power supply allows you to power the monitor from a mains outlet via the 4-pin XLR port, or you can power it from a Gold mount battery using the included battery plate. The monitor comes with a mounting bracket for desktop use and a VESA mounting plate for mounting in the field.
Features
Monitoring Tools
- Peaking
- Check field
- Image rotation/flip
- Overscan
- Underscan
- Image freeze
- Pixel-to-pixel
- False color
- Exposure
- Histogram
- Timecode (SDI-only)
- Aspect ratio selection
- Screen markers
- Color space
- HDR
- Color temperature adjustment
HDR and 3D LUTs
Supported Log Formats
Supported HDR
Audio
Assignable Buttons
Remote Control
Calibration
Fiber
Screen Protector
In the Box
- Lilliput 31.5" 12G-SDI/HDMI Broadcast Studio Monitor (Gold Mount)
- Gold Mount Battery Plate
- Power Adapter
- VESA Mount Plate
- Base Bracket
- USB Flash Disk
- Acrylic Screen Protector
- Limited 1-Year Warranty
Lilliput Q31 Specs
| Display Size | 31.5" / 80.0 cm |
| Resolution | 3840 x 2160 |
| Aspect Ratio | 16:9 |
| Viewing Angle | Horizontal: 178° Vertical: 178° |
| Touchscreen | No |
| Maximum Brightness | 350 cd/m2 |
| Contrast Ratio | 1300:1 |
| HDR Compatibility | Hybrid Log Gamma |
| Pixels Per Inch (ppi) | 139 ppi |
| Real-Time LUT Monitoring | HDR |
| Image Controls | Blue Only, Check Field, Color Temperature Selection, False Color, Focus Peaking, Green Only, H/V Delay, Histogram, Pixel-to-Pixel Zoom, Red Only, Scaling, Screen Markers, Screen Split - Half, Screen Split - Quarter, Underscan, Vectorscope, Waveform, Zebra |
| Video | 1 x HDMI Type A (HDMI 2.0) Input 2 x BNC (12G-SDI) Input 2 x BNC (3G-SDI) Input 1 x HDMI Type A (HDMI 2.0) Output 2 x BNC (12G-SDI) Output 2 x BNC (3G-SDI) Output |
| Embedded Audio | HDMI: 8-Channel SDI: 16-Channel |
| Audio | 1 x 1/8" / 3.5 mm Headphone Output |
| Built-In Speaker | 2 |
| Power | 1 x 4-Pin XLR (24 VDC) Input |
| Other I/O | 1 x GPI (RJ45) Input 1 x LAN (RJ45) Input 1 x RS-422 (RJ45) Input 1 x RS-422 (RJ45) Output 1 x USB 2.0 (USB Type-A) Input |
| Media/Memory Card Slot | None |
| Wi-Fi | None |
| Video Format | HDMI DCI 4K: 60/50/30/25/24 UHD 4K: 60/50/30/25/24 1080p: 60/50/30/25/24 1080i: 60/50 720p: 60/50 SDI DCI 4K: 60/50/30/25/24 UHD 4K: 60/50/30/25/24 1080p: 60/50/30/25/24 1080PsF: 30/25/24 1080i: 60/50 720p: 60/50 |
| DC Input Power | 12 to 24 VDC at 1.2 A |
| Battery Type | 1 x Gold Mount |
| Power Consumption | 65 W |
| Operating Temperature | 32 to 104°F / 0 to 40°C |
| Storage Temperature | -4 to 140°F / -20 to 60°C |
| Material of Construction | Metal |
| Dimensions | 28.2 x 17.9 x 1.9" / 717.5 x 454.7 x 47.4 mm |
| Weight | 26.5 lb / 12 kg |
| Warranty Length | Limited 1-Year Warranty |
| Package Weight | 35 lb |
| Box Dimensions (LxWxH) | 33 x 23.13 x 6.13" |
