HO 60-NP-0100 is a HO-NP series current transducer for the electronic measurement of current DC, AC, pulsed with galvanic separation between the primary and the secondary circuit. Typical applications include AC variable speed and servo motor drives, static converters for DC motor drives, battery supplied applications, uninterruptible power supplies (UPS), switched mode power supplies (SMPS), power supplies for welding applications, combiner box and solar inverter on DC side of the inverter (MPPT).
- Open loop multi-range current transducer
- Voltage output
- Single power supply of +5V
- Over-current detect 2.93 � IPN (peak value)
- EEPROM control
- Galvanic separation between primary and secondary circuit
- Low power consumption
- Compact design for THT PCB mounting
- Factory calibrated
Product details
| Sensor Output:
Voltage
|
| Supply Voltage DC Min:
4.5V
|
| Supply Voltage DC Max:
5.5V
|
| Current Measuring Range DC:
-150A to 150A
|
| Current Measuring Range AC:
-150A to 150A
|
| Response Time:
2.5µs
|
| Accuracy %:
1.4%
|
| Product Range:
HO-NP Series
|
Other details
| Brand |
LEM |
| Part Number |
HO 60-NP-0100 |
| Quantity |
Each |
| Technical Data Sheet EN |
 |
