Product Overview
- Continuous tone piezo indicator (active buzzer)
- High SPL, high / low temperature resistant
- Pin type installation
- 3.5KHz±500KHz frequency, 15.0mA at 5VDC maximum current consumption
- 85dB (typical 90) at 10cm/5VDC minimum SPL
- PPO (black) material
- Operation temperature range from -35 to 75°C
- Dimension is 23.50 x 16.00mm
Product details
Technical Specifications
Transducer Function
Buzzer
Sound Pressure Level (SPL)
85dB
Transducer Mounting
Through Hole
Housing Material
PPO (Polyphenylene Oxide)
Operating Temperature Min
-35°C
Resonant Frequency
3.5kHz
Operating Current Max
15mA
Sound Level Distance
100mm
Operating Voltage Range
3VDC to 15VDC
Operating Temperature Max
75°C
Other details
| Brand |
KINGSTATE |
| Part Number |
KPEG216-5V |
| Quantity |
Each |
| Technical Data Sheet EN |
 |
