Description
Key Digital KD-VW4X4PROK Overview
The 4x4 4K UHD HDMI Video Wall Processor, Seamless 4x4 Matrix Switcher with 4 RX Units from Key Digital is a 4 x HDMI input with 4 x HDMI + 4 x UHDoTP mirrored output video wall processor and seamless matrix switcher with independent audio routing. The KD-VW4x4ProK is perfect for video wall and large format viewing applications like Bar & Restaurant, Sports & Gaming Caves, Digital Signage, House of Worship, Entertainment Centers, Museums, E-Sports, and more. KD-VW4x4ProK has been specially engineered to create video walls with consumer panels and monitors.
The Panel Flip feature rotates the image 180 degrees on the desired outputs, enabling the top row of monitors to be installed upside down, conjoining the narrow frame sides of the displays. Bezel Compensation allows the image to be extended off the screen to create fluid screen transition and five supported video wall layouts (2x2, 4x1, 3x1, 2 mirrored sets of 2x1, and 1x4) make KD-VW4x4ProK the ideal choice to build video walls in any application and price point. Mirrored HDMI and Cat 6 AV outputs enable up to eight connected displays via the four included Rx units, ideal for dual video walls showing the same thing at the same time.
- Video wall processing: transform consumer and professional displays into a video wall with five video wall modes: 2x2, 4x1, 3x1, 2 sets of 2x1, and 1x4
- Seamless switching: uninterrupted screen transitions during source selection
- Built-in UHDoTP Tx with PoC: 4 included KD-EXMLVRx units are powered by KD-VW4x4ProK
- Dual video wall / mirrored outputs: simultaneously active HDMI + UHDoTP connections per output show same AV signal at same time for a total of 8 possible displays connected
- Video resolution: up to 3840 x 2160p 4:2:0 at 60fps supported on inputs & 3840 x 2160p 4:4:4 at 30fps supported on outputs
- Panel flip: enables use of consumer displays by mounting top row upside down and conjoining narrow frame sides
- Bezel compensation: create a fluid screen transition by removing pixels from top, bottom, left, and right border independently
- Signal extension over CAT: 4K/UHD up to 115ft using CAT5e/6, up to 131ft using CAT6A STP, 1080p up to 164ft using CAT5e/6, up to 197ft using CAT6A STP
- Text overlay: assigned name of each source may be displayed in each window. 16 characters maximum with variable sizing and location settings
- 4K down-convert: integrate 4K sources with legacy 1080p & 720p displays
- Built-in test patterns: 9 selectable test screens help expedite installation
- IR extension: extend IR via Rx units to control displays or collect IR from remote to control a source at matrixWeb UI: Control AV routing and other basic functions from any web browser
- Audio de-embed: 6 pin balanced / unbalanced and digital optical outputs
- Dolby Digital & DTS Audio: supports 2-channel and multi-channel surround formats up to 5.1 Dolby / DTS
- Control: front-panel buttons, IR, RS-232, TCP-IP, and Web Control
- Key Digital app ready: can be controlled over TCP/IP via Key Digital App
- Control system support: Key Digital app ready. Key Digital Management Software Pro (KDMS Pro) ready, Compass Control Pro ready. Fully controllable by all IR, RS-232, and TCP/IP supported control systems via open API
- HDCP 2.2 licensing: fully licensed and compatible with HDCP 2.2 full buffer system: manages TMDS re-clocking / signal re-generation, HDCP authentication to source & display, and EDID handshake to source
- EDID management: internal library with 8 EDID AV handshakes per input, in addition to ability to copy from any connected display / output
- TMDS re-clocking: supports long HDMI connectivity using Key Digital HDMI cables
- Deep Color support: up to 8-bit/color
In the Box
- Key Digital 4x4 4K UHD HDMI Video Wall Processor, Seamless 4x4 Matrix Switcher with 4 RX Units
- 12V 5A Screw-Type Power Supply
- Remote Control
- 4 x IR Emitters with 3.5mm Mono End (6')
- 4 x IR Sensors with 3.5mm 4 Conductor End (6')
- 4 x 6-Pin Phoenix Connector for Audio (Blue)
- 6-Pin Phoenix Connector for Unit Control
- Micro to Type-A USB 2.0 Data Cable (6')
- 2 x Rack Ear
- Limited 3-Year Manufacturer Warranty
Key Digital KD-VW4X4PROK Specs
| Input |
4 x HDMI (12G-SDI)
|
| Output |
8 x HDMI
|
| Input |
4 x HDMI (12G-SDI)
|
| Output |
8 x HDMI
|
| Other I/O |
8 x RJ45
4 x 1/8" / 3.5 mm (IR) Input 4 x 1/8" / 3.5 mm (IR) Output 4 x 1/8" / 3.5 mm (IR) Input/Output |
| HDR Compatibility |
No
|
| HDCP Support |
No
|
| EDID Support |
No
|
| Rack Form Factor |
1 RU
|
| Dimensions |
17.2 x 9.4 x 1.7" / 438.0 x 237.7 x 44.0 mm
|
| Weight |
8.02 lb / 3.64 kg
|
| Package Weight |
13.83 lb
|
| Box Dimensions (LxWxH) |
19.8 x 14.8 x 5.2"
|
