The TRS5-40BCR01 from KEMET is a TRS� series thermal reed switch. It is a highly reliable, precise temperature-sensitive switch ideal for energy conservation. The TRS Series is composed of a magnet and a temperature-sensing soft ferromagnetic substance called Thermorite®. The material's magnetic flux density decreases as the temperature increases, turning it into a paramagnetic substance at its curie temperature. Typical applications include temperature detection and overheat monitoring of electric appliances, heat-retention heater control for rice cookers, defrost for air conditioners and vending machines, roll heater temperature control for copying machines, radiator water temperature detection for automotive electric fan control.
Other details
| Brand |
KEMET |
| Part Number |
TRS5-40BCR01 |
| Quantity |
Each |
| Technical Data Sheet EN |
 |
| Manufacturer Catalogue EN |
|
| CAD Multiple Formats EN |
|
