The KEMET Organic Capacitor (KO-CAP) is a solid electrolytic capacitor with a conductive polymer cathode capable of delivering very low ESR and improved capacitance retention at high frequencies. KO-CAP combines the low ESR of multilayer ceramic, the high capacitance of aluminium electrolytic and the volumetric efficiency of tantalum into a single surface mount package. Unlike liquid electrolyt
- Ultra-low ESR
- Complies with AEC-Q200 Qualification Test Plan
- High reliability up to 1,000 hours with 85°C/85% RH load
- Subject to PPAP/PSW and Change Control
- Meets or exceeds EIA standard 535BAAC
Product details
| Capacitance |
330µF |
| Voltage Rating |
6.3V |
| Product Range |
T598 KO-CAP® Series |
| Capacitance Tolerance |
± 20% |
| Manufacturer Size Code |
D |
| ESR |
0.025ohm |
| Operating Temperature Min |
-55°C |
| Operating Temperature Max |
125°C |
| Automotive Qualification Standard |
AEC-Q200 |
Other details
| Brand |
KEMET |
| Part Number |
T598D337M006ATE025 |
| Quantity |
Each (Supplied on Cut Tape) |
| Technical Data Sheet EN |
 |
| CAD Multiple Formats EN |
|
| Product Change Notice EN |
|
| Manufacturer Catalogue EN |
|
