Kemet T591D686M020ATE040 Tantalum Polymer Capacitor 68 µF ± 20% 20 V D 0.04 ohm 2917 [7343 Metric]

The T591 series organic SMD Tantalum Capacitor with a conductive polymer cathode capable of delivering very low ESR and improved capacitance retention at high frequencies. KO-CAP combines the low ESR of multilayer ceramic, the high capacitance of aluminium electrolytic and the volumetric efficiency of tantalum into a single surface mount package. Unlike liquid electrolyte-based capacitors, KO-CAP has a very long operational life and high ripple current capabilities. This high humidity/high temperature polymer electrolytic series delivers higher capacitance and ESR stability under harsh environmental conditions.

• Qualification plan based on AEC-Q200 with 85°C/85% RH
• Meets or exceeds EIA standard 535BAAC
• Capacitance up to 1500µF
• 6.3 to 16V Voltage range
• 100% Accelerated steady state aging
• 100% Surge current tested
• 100% Thermal shock
• Volumetric efficiency
• Self-healing mechanism

Warnings Market demand for this product has caused an extension in leadtimes. Delivery dates may fluctuate. Product exempt from discounts.

Other details

Brand	KEMET
Part Number	T591D686M020ATE040
Quantity	Each (Supplied on Cut Tape)
Technical Data Sheet EN
Manufacturer Catalogue EN
CAD Multiple Formats EN
