Kemet T521X107M025ATE060 Tantalum Polymer Capacitor KO-CAP® 100 µF ± 20% 25 V X 0.06 ohm 2917 [7343 Metric]

The T521X107M025ATE060 is a high voltage polymer electrolytic Tantalum Capacitor with 100% matte tin (Sn)-plated termination. The Organic Capacitor (KO-CAP®) is a solid electrolytic capacitor with a conductive polymer cathode capable of delivering very low ESR and improved capacitance retention at high frequencies. KO-CAP combines the low ESR of multilayer ceramic, the high capacitance of aluminium electrolytic and the volumetric efficiency of tantalum. Unlike liquid electrolyte-based capacitor, KO-CAP has a very long operational life and high ripple current capabilities. The T521 high voltage polymer electrolytic is designed for higher application voltages than the T520 KO-CAP. The low ESR of the T521 provides high ripple current capability. KO-CAP's long-life reliability enables the T521 to be an ideal alternative to liquid-based electrolytic capacitor.

• Volumetrically efficient
• Stable temperature characteristics
• High ripple current capability
• High reliability
• 100% Surge current tested
• Low profile design
• Halogen-free
• High frequency capacitance retention
• 100% Accelerated steady state aging
• 250µA at 25°C/5 minutes Maximum DC leakage current
• 2000mA at 45°C/100kHz Maximum allowable ripple current

Applications

Power Management, Aerospace, Defence, Military

Warnings Market demand for this product has caused an extension in leadtimes. Delivery dates may fluctuate. Product exempt from discounts.

Other details

Brand	KEMET
Part Number	T521X107M025ATE060
Quantity	Each (Supplied on Cut Tape)
Technical Data Sheet EN
Manufacturer Catalogue EN
Product Change Notice EN
CAD Multiple Formats EN
