The T521 series organic SMD Tantalum Capacitor with a conductive polymer cathode capable of delivering very low ESR and improved capacitance retention at high frequencies. KO-CAP combines the low ESR of multilayer ceramic, the high capacitance of aluminium electrolytic and the volumetric efficiency of tantalum into a single surface mount package. Unlike liquid electrolyte-based capacitors, KO-CAP has a very long operational life and high ripple current capabilities. This high voltage polymer electrolytic is designed for higher application voltages than the T520 KO-CAP. KO-CAP's long-life reliability enables this series to be an ideal alternative to liquid-based electrolytic capacitors.
- Volumetrically efficient
- Stable temperature characteristics
- High ripple current capability
- High reliability
- 100% Surge current tested
- Low profile design
- Halogen-free epoxy
- High frequency capacitance retention
- 100% Accelerated steady state aging
Product details
| Capacitance:
68µF
|
| Capacitance Tolerance:
± 20%
|
| Voltage(DC):
16V
|
| Manufacturer Size Code:
V
|
| ESR:
0.09ohm
|
| Capacitor Case / Package:
2917 [7343 Metric]
|
| Product Length:
7.3mm
|
| Product Width:
4.3mm
|
| Product Height:
1.8mm
|
| Ripple Current:
1.4A
|
| Operating Temperature Min:
-55°C
|
| Operating Temperature Max:
105°C
|
| Product Range:
T52X/T530 KO-CAP® Series
|
| Qualification:
-
|
Other details
| Brand |
KEMET |
| Part Number |
T521V686M016ATE090 |
| Quantity |
Each (Supplied on Cut Tape) |
| Technical Data Sheet EN |
 |
All product and company names are trademarks™ or registered® trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them.
![KEMET T521V686M016ATE090 Tantalum Polymer Capacitor, KO-CAP®, 68 µF, ± 20%, 16 V, V, 0.09 ohm, 2917 [7343 Metric]](http://www.tanotis.com/cdn/shop/files/0d6fd99d64a6812f37c9a01b78a0f7c7_8f0b5d8f-efc9-4d62-a061-89fb53732466_{width}x.jpg?v=1706909824)
