Kemet T520V337M2R5ATE025 Tantalum Polymer Capacitor KO-CAP® 330 µF ± 20% 2.5 V 0.025 ohm 2917 [7343 Metric]

The T520V337M2R5ATE025 is a low ESR polymer electrolytic Tantalum Capacitor with 100% matte tin (Sn)-plated termination and 2917 case. The Organic Capacitor (KO-CAP) is a solid electrolytic capacitor with a conductive polymer cathode capable of delivering very low ESR and improved capacitance retention at high frequencies. KO-CAP combines the low ESR of multilayer ceramic, the high capacitance of aluminium electrolytic and the volumetric efficiency of tantalum. Unlike liquid electrolyte-based capacitors, KO-CAP has a very long operational life and high ripple current capabilities. The T520 low ESR polymer electrolytic provides the widest range of voltage, capacitance and case size options in the KO-CAP family. Suitable for general purpose DC applications up to 12.8V, the T520 is ideal for DC-to-DC converters, bulk decoupling and hold-up.

• Volumetrically efficient
• High frequency capacitance retention
• 100% Accelerated steady state aging
• 100% Surge current tested
• Halogen-free
• 83µA at 25°C/5 minutes Maximum DC leakage current
• 2700mA at 45°C/100kHz Maximum allowable ripple current

Applications

Power Management, Computers & Computer Peripherals, Portable Devices, Communications & Networking, Consumer Electronics

Warnings Market demand for this product has caused an extension in leadtimes. Delivery dates may fluctuate. Product exempt from discounts.

Other details

Brand	KEMET
Part Number	T520V337M2R5ATE025
Quantity	Each (Supplied on Cut Tape)
Technical Data Sheet EN
CAD Multiple Formats EN
Product Change Notice EN
Manufacturer Catalogue EN
Application Note EN
