Kemet T520T227M004ATE025 T520T227M004ATE025 Tantalum Polymer Capacitor 220 µF ± 20% 4 V T 0.025 ohm 1411 [3528 Metric]

T520 Standard series polymer electrolytic organic capacitor (KO-CAP®) is a solid electrolytic capacitor with a conductive polymer cathode capable of delivering very low ESR and improved capacitance retention at high frequencies. KO-CAP combines low ESR of multilayer ceramic, the high capacitance of aluminium electrolytic and volumetric efficiency of tantalum into a single surface mount package. It provides widest range of voltages, capacitance and case size options in KO-CAP family and is suitable for general purpose DC applications for up to 48VDC voltage rails. Applications include DC/DC converters, audio/sound circuits (mobile phone, base stations, smart phones, MP3 players), power supply inputs, portable electronics (notebook PCs, displays, SSDs, HDDs and USBs, digital cameras, GPS navigation systems, Wi-Fi modules), telecommunications, consumer electronics (analytical and test equipment, high speed servers), high voltage applications such as 12V to 48V power input rails.

• Stable capacitance across temperature and voltage
• No aging effects
• Suitable for high ripple current applications with high ripple handling capability
• Volumetrically efficient
• High frequency capacitance retention
• 100% accelerated steady state aging
• 100% surge current tested
• Epoxy compliant with UL94 V-0
• KO-CAP has very long operational life, high ripple current capabilities
• Used in densely populated circuits with space restrictions, microprocessor decoupling

Other details

Brand	KEMET
Part Number	T520T227M004ATE025
Quantity	Each (Supplied on Cut Tape)
Technical Data Sheet EN
