Kemet T520D227M010ATE025 Tantalum Polymer Capacitor KO-CAP® 220 µF ± 20% 10 V D 0.025 ohm 2917 [7343 Metric]

The T520 series Organic Capacitor (KO-CAP) is a solid electrolytic capacitor with a conductive polymer cathode capable of delivering very low ESR and improved capacitance retention at high frequencies. KO-CAP combines the low ESR of multilayer ceramic, the high capacitance of aluminium electrolytic and the volumetric efficiency of tantalum into a single surface mount package. Unlike liquid electrolyte-based capacitors, KO-CAP has a very long operational life and high ripple current capabilities. Suitable for general purpose DC applications up to 12.8V. This series is ideal for DC-to-DC converters, bulk decoupling and hold-up.

• Volumetrically efficient
• High frequency capacitance retention
• 100% Accelerated steady state aging
• 100% Surge current tested
• EIA standard case sizes
• Halogen-free epoxy

Warnings Market demand for this product has caused an extension in leadtimes. Delivery dates may fluctuate. Product exempt from discounts.

Other details

Brand	KEMET
Part Number	T520D227M010ATE025
Quantity	Each (Supplied on Cut Tape)
Technical Data Sheet EN
CAD Multiple Formats EN
Application Note EN
Manufacturer Catalogue EN
Product Change Notice EN
