Kemet T510X477K006ATE030 Surface Mount Tantalum Capacitor 470 µF 6.3 V 2917 [7343 Metric] ± 10% 0.03 ohm X

The T510 series multiple anode MnO2 SMD Tantalum Capacitor designed for demanding applications that require high surge current and high ripple current capability. This capacitor builds upon the proven capabilities of our industrial grade tantalum chip capacitor to offers several advantages such as low ESR, high ripple current capability, excellent capacitance stability and improved resistance to high in-rush currents. These benefits are achieved though the utilization of multiple anodes as well as high-stress, low impedance electrical conditioning performed prior to screening.

• Meets or exceeds EIA Standard 535BAAC
• High surge current capability
• Optional gold-plated terminations
• High ripple current capability
• 100% Surge current test
• 100% Steady-state accelerated aging
• 10 to 100µF Capacitance range
• 4 to 50V Voltage range
• Case sizes E and X
• Moisture sensitivity level-1

Warnings Market demand for this product has caused an extension in leadtimes. Delivery dates may fluctuate. Product exempt from discounts.

Other details

Brand	KEMET
Part Number	T510X477K006ATE030
Quantity	Each (Supplied on Cut Tape)
Technical Data Sheet EN
Manufacturer Catalogue EN
CAD Multiple Formats EN
Product Change Notice EN
