Description
This is a MPX1D1235LR68 Power Inductor (SMD) , 680 nH, 25.9 A, Shielded, 28 A, MPX Series, 13.2mm x 12.5mm x 3.5mm product from KEMET with the model number MPX1D1235LR68
Product details
| Inductance | 680nH |
| RMS Current (Irms) | 25.9A |
| Inductor Construction | Shielded |
| Saturation Current (Isat) | 28A |
| Product Range | MPX Series |
| Power Inductor Case | 13.2mm x 12.5mm x 3.5mm |
| DC Resistance Max | 0.0029ohm |
| Inductance Tolerance | ± 20% |
Other details
| Brand | KEMET |
| Part Number | MPX1D1235LR68 |
| Quantity | Each (Supplied on Cut Tape) |
| Technical Data Sheet EN |  |
| CAD Multiple Formats EN | |
| Manufacturer Catalogue EN | |
