| ₹ 1806.54 includes GST and import duties. | |
| B2B customers can avail ₹ 275.5 ITC on this product | |
| 100% Secure Payments | 100% Genuine product |
Description
Product Overview
ALA8AA331CD450 is a ALA8A series snap-in aluminium electrolytic capacitor designed for automotive applications. Typical applications for the ALA8A capacitor is mainly in the field of e-mobility, such as on-board chargers, inverters, or wall boxes.
- AEC -Q200 qualified
- Can withstand vibration up to 10g
- Excellent surge voltage capability
- High ripple current and high voltage
- Operational lifetime of 5,000 hours at +105°C (VR IR applied)
- PET sleeve and Lexan disc are recognized to UL: QMTR2, UL No. E358957
- Operating temperature range from -40 to +105°C
- Capacitance value is 330µF and product size (height x diameter) is 40mm x 30mm
- Capacitance tolerance of ±20% at 100Hz/+20°C
- Rated voltage of 450V
Product details
Other details
| Brand | KEMET |
| Part Number | ALA8AA331CD450 |
| Quantity | Each |
| Technical Data Sheet EN |  |
All product and company names are trademarks™ or registered® trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them.
Bulk Discount
| Quantity | Price |
| 2 | ₹ 1770.41 |
| 3-5 | ₹ 1752.34 |
| 5-10 | ₹ 1716.21 |
| 10+ | ₹ 1680.08 |
Bulk discount will be automatically applied during checkout based on quantity.
