Description
Product Overview
ALA8AA271DC500 is a ALA8A series snap-in aluminium electrolytic capacitor designed for automotive applications. Typical applications for the ALA8A capacitor is mainly in the field of e-mobility, such as on-board chargers, inverters, or wall boxes.
- AEC -Q200 qualified
- Can withstand vibration up to 10g
- Excellent surge voltage capability
- High ripple current and high voltage
- Operational lifetime of 5,000 hours at +105°C (VR IR applied)
- PET sleeve and Lexan disc are recognized to UL: QMTR2, UL No. E358957
- Operating temperature range from -40 to +105°C
- Capacitance value is 270µF and product size (height x diameter) is 35mm x 35mm
- Capacitance tolerance of ±20% at 100Hz/+20°C
- Rated voltage of 500V
Product details
Other details
| Brand | KEMET |
| Part Number | ALA8AA271DC500 |
| Quantity | Each |
| Technical Data Sheet EN |  |
