The A767 Series are Surface Mount Conductive Polymer Aluminum Solid Electrolytic Capacitors. They offer longer life and greater stability across a wide range of temperatures. The A767 Series highly conductive solid polymer electrolyte eliminates the risk of explosion from drying out and due to its low ESR properties is able to withstand higher ripple currents during normal operation. The A767 Series are ideally suited for industrial and commercial applications.
- 2,000 hours @ 105°C
- Ultra low impedance
- High ripple current
- High voltage
- Surface mount form factor
Product details
| Capacitance |
47µF |
| Voltage Rating |
63V |
| AE Capacitor Case |
Radial Can - SMD |
| Product Range |
A767 Series |
| ESR |
0.036ohm |
| Lifetime @ Temperature |
2000 hours @ 105°C |
| Operating Temperature Min |
-55°C |
| Operating Temperature Max |
105°C |
| Automotive Qualification Standard |
- |
| RoHS Phthalates Compliant |
Yes |
Other details
| Brand |
KEMET |
| Part Number |
A767KS476M1JLAE036 |
| Quantity |
Each (Supplied on Cut Tape) |
| Technical Data Sheet EN |
 |
| Manufacturer Catalogue EN |
|
