Description
KanexPro CAS70MRX Overview
The 4K HDMI Cascading Extender Receiver from KanexPro receives HDMI signals with up to UHD 4K60 resolution beyond from up to 230' away over a single Cat 6/6e/7e cable with no latency. The receiver unit features an RJ45 input and HDMI output and works with a separately available transmitter, and it supports cascading up to 10 additional receivers to extend the transmission even farther.
The receiver also includes a S/PDIF TOSLINK optical output to de-embed audio from the transmission. It also supports bidirectional IR pass-through, HDCP 2.2, EDID, and HDR support.
Applications
For use in digital signage applications, healthcare AV, control rooms, educational facilities, airports, commanding centers, and home theater
Key Features
Compact receiver kit for extending HDMI signals
Zero latency
Supports 4K transmission distance up to 230'
Cascade up to 10 additional receivers
Receiver unit can individually manage display resolution and EDID
Supports up to UHD 4K60 video and HDR YUV 4:4:4
Bidirectional IR pass-through 20 to 60 kHz with included kit
Supports ARC S/PDIF digital audio de-embedded output
HDCP 2.2 and EDID support for multiple displays
Simple setup with zero configuration
Compact design for flexible installations
UPC: 813982022775
In the Box
- KanexPro 4K HDMI Cascading Extender Receiver over Cat 6 (230')
- IR Pass-Through Kit
KanexPro CAS70MRX Specs
Interfaces
| Inputs | 1 x RJ45 Female |
| Outputs | 1 x HDMI (HDMI 2.0) Female 1 x TOSLINK (S/PDIF) Female |
| Embedded Audio Output | HDMI RJ45 |
| Other I/O | 1 x RJ45 Output |
Standards
| HDCP Support | Version 2.2 |
| EDID Support | Yes |
Transmission
| Max Transmission Distance | UHD 4K: 229.7' / 70 m (via Cat 6/6a/7) |
| Video Format | HDMI Input (4:4:4 YUV) UHD 4K: 60 fps 1080p: 60 fps 1080i: 60 fps 720p: 60 fps 576p: 60 fps PAL: 60 fps 480p: 60 fps NTSC: 60 fps |
| PC Resolutions | HDMI: 1280 x 960 HDMI: 1280 x 800 HDMI: 1280 x 768 HDMI: 1680 x 1050 HDMI: 1360 x 768 HDMI: 1600 x 900 HDMI: 1024 x 768 HDMI: 800 x 600 |
| Audio Format | S/PDIF: |
| Supported Cable Types | Cat 5e/6/6a/6e/7 |
| Latency | 0 ms |
Power
| Power Connector | 1 x Barrel (5 to 12 VDC) Input |
| Power Consumption | Power Supply: 100 to 240 VAC (4 W) |
Environmental
| Operating Temperature | -4 to 140°F / -20 to 60°C |
| Storage Temperature | -22 to 158°F / -30 to 70°C |
| Operating Humidity | 0 to 90% |
General
| Dimensions | 4.2 x 3.9 x 1" / 106 x 99 x 26.2 mm |
| Weight | 7.4 oz / 210 g |
Packaging Info
| Package Weight | 1.215 lb |
| Box Dimensions (LxWxH) | 7.9 x 6.1 x 3.3" |
