| ₹ 18325.0 includes GST and import duties. | |
| B2B customers can avail ₹ 2794.56 ITC on this product | |
| 100% Secure Payments | 100% Genuine product | |
| The product is eligible for Free Shipping |
Description
IOGEAR GVE4K60KIT Overview
- 1Description
- 2Extend or Split
- 3Long-Range Transmission
- 4Bi-Directional IR
- 5Additional Features
Transmit a UHD-quality signal over long distances with the GVE4K60KIT 4K Video Extender/Splitter Over Cat 6 Kit from IOGEAR. The kit is an ideal solution for a home theater, but can be expanded to accommodate commercial applications. The transmitter can send a 4K signal (3840 x 2160) at 60 Hz with 4:4:4 chroma subsampling over a Cat 6 network with near zero latency (1 ms). This is ideal for smooth movie playback and responsive gaming. With up to nine additional receiver units (not included), you can split a singular signal across multiple displays.
Extend or Split
With this kit as-is, you can extend an HDMI signal over Cat 6 in 1-to-1 Mode, which is great for watching a movie on Blu-ray when your player is in a media cabinet in a separate room from your TV or projection screen. With optional additional receivers, you can use Splitter Mode to send the same signal to multiple displays. This is ideal for showcasing advertising or other public-facing information in a large area.
Long-Range Transmission
Utilizing Cat 6 cabling across a network, you can send a signal up to 230' away to the first receiver. When using additional receivers, the distance between cascading receivers remains decently long at up to 165'.
Bi-Directional IR
Control goes both way with this IOGEAR extender/splitter kit. The playback source can be controlled from a display-side receiver, and the receiver-side display can be controlled from the source.
Additional Features
- Supports a maximum resolution of up to 4K (4096 x 2160) at 30 Hz
- S/PDIF digital audio output with support for LPCM, DTS-HD, DTS, Dolby TrueHD 7.1, and Dolby Digital 5.1
- HDMI ARC Support
- Aluminum housing for improved heat dissipation
- Electrostatic surge protection
- Supports HDMI CEC
- Meets CE, FCC, and RoHS certification standards
UPC: 881317520425
In the Box
- IOGEAR GVE4K60KIT 4K Video Extender/Splitter Over Cat 6 Kit
- Transmitter
- Receiver
- 2 x IR Extension Cables
- 2 x Power Adapters
- 2 x Mounting Kits
Table of Contents
- Description
- Extend or Split
- Long-Range Transmission
- Bi-Directional IR
- Additional Features
IOGEAR GVE4K60KIT Specs
Transmission
| Max Transmission Distance | 4K DCI at 30 Hz: 230' / 70.1 m (via Cat 6) 4K UHD at 60 Hz: 230' / 70.1 m (via Cat 6) |
| Video Format | HDMI 4K DCI: 30p HDMI 4K UHD: 60p |
| Audio Format | S/PDIF: Dolby Digital, DTS, Dolby TrueHD, DTS-HD, PCM Audio |
Transmitter Interfaces
| Input Connectors | 1 x HDMI Type A Female 1 x 1/8" / 3.5 mm (IR) Female |
| Outputs | 1 x RJ45 (LAN) Female 1 x HDMI (Loop-Through) Female 1 x 1/8" / 3.5 mm (IR) Female |
Receiver Interfaces
| Inputs | 1 x RJ45 (LAN) Female 1 x 1/8" / 3.5 mm (IR) Female |
| Outputs | 1 x HDMI Female 1 x RJ45 (LAN) Female 1 x TOSLINK Optical (S/PDIF) Female 1 x 1/8" / 3.5 mm (IR) Female |
Standards
| HDCP Support | None |
| EDID Support | Yes |
Power
| Transmitter Power Connector | 1 x Barrel (5 VDC) Input |
| Receiver Power Connector | 1 x Barrel (5 VDC) Input |
General
| Certifications | CE, FCC, RoHS *as per Manufacturer |
| Transmitter Dimensions | 4.13 x 4.13 x 0.75" / 10.49 x 10.49 x 1.91 cm |
| Receiver Dimensions | 4.13 x 4.13 x 0.75" / 10.49 x 10.49 x 1.91 cm |
| Transmitter Weight | 1.1 lb / 0.5 kg |
| Receiver Weight | 1.1 lb / 0.5 kg |
Packaging Info
| Package Weight | 2.03 lb |
| Box Dimensions (LxWxH) | 9.7 x 7.2 x 3.3" |
IOGEAR GVE4K60KIT Reviews
All product and company names are trademarks™ or registered® trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them.
Bulk Discount
| Quantity | Price |
| 2 | ₹ 17958.5 |
| 3-5 | ₹ 17775.25 |
| 5-10 | ₹ 17408.75 |
| 10+ | ₹ 17042.25 |
Bulk discount will be automatically applied during checkout based on quantity.
