Description
IOGEAR Dock Pro Overview
- 1Description
- 2
- 3Triple 4K Displays
- 4Goshen Ridge Controller
- 58K Single View Support
- 6Dual USB4 Ports
- 72.5 Gigabit Ethernet Port (10/100/1000/2500Mb)
By Photo's
John-Paul Palescandolo
Designed for users looking to expand the connectivity of their USB4 or Thunderbolt 4 system, the
Dock Pro USB4 8K Triple View Docking Station from
IOGEAR is compatible with Windows and Mac. It connects to your host system using a 40 Gb/s USB4 / USB-C port, which provides up to 96W of power. The dock itself is powered using either an included 150W AC adapter. Also featured are two 40 Gb/s USB4 / USB-C ports that support 8K/30 Hz, a 10 Gb/s USB-C 3.2 Gen 2 port that provides up to 30W of power, two 10 Gb/s USB-A 3.2 Gen 2 ports, one 5 Gb/s USB-A 3.2 Gen 1 port, a 2.5 Gigabit Ethernet port, a 3.5mm audio combo jack, a UHS-II SD card reader, and a UHS-II microSD card reader. There are also two 4K/60Hz HDMI outputs and two 8K/30 Hz DisplayPort outputs, so you'll be able to connect up to three 4K displays to this dock.
Triple 4K Displays
Mirror or extend your displays with support for up to three simultaneous monitors. This dock can drive one 8K/30 Hz display, two 4K/60 Hz displays, or one 4K/30 Hz and two 4K/60 Hz displays.
Goshen Ridge Controller
The Goshen Ridge controller supports Thunderbolt 4 at its max bandwidth of 40 Gb/s. Available ports include HDMI, DisplayPort, USB4, USB-C 3.2 Gen 2, USB-A 3.2 Gen 2, USB-A 3.2 Gen 1, 2.5Gb Ethernet, 3.5mm headphone/mic, and UHS-II SD and microSD card readers.
8K Single View Support
This dock supports one 8K/30 Hz display, using either of its DisplayPort or USB4 outputs.
Dual USB4 Ports
In addition to 8K/30 Hz video, each USB4 port supports data transfers up to 40 Gb/s.
2.5 Gigabit Ethernet Port (10/100/1000/2500Mb)
Achieve network connectivity at speeds up to 2.5GbE using the integrated RJ45 port.
Host Device Requirements
- USB4 or Thunderbolt 4 host required for max 40 Gb/s bandwidth
- USB-C (DP Alt mode) and Thunderbolt 3 hosts are compatible at a lower bandwidth
In the Box
- IOGEAR Dock Pro USB4 8K Triple View Docking Station
- USB4 / USB-C Cable (2.6' / 0.8 m)
- Power Adapter
- Limited 1-Year Manufacturer Warranty
Table of Contents
- Description
- Triple 4K Displays
- Goshen Ridge Controller
- 8K Single View Support
- Dual USB4 Ports
- 2.5 Gigabit Ethernet Port (10/100/1000/2500Mb)
IOGEAR Dock Pro Specs
Key Specs
| USB I/O |
2x USB-C (USB4) / Supports Video Alt Mode
1x USB-C 3.1/3.2 Gen 2 / Supports 30 W Output 2x USB-A 3.1/3.2 Gen 2 1x USB-A 3.0 / 3.1/3.2 Gen 1 |
| Network I/O |
1x RJ45 (2.5 Gb/s)
|
| Video I/O |
2x DisplayPort
2x HDMI |
| Audio I/O |
1x 1/8" / 3.5 mm Headphone/Microphone Combo Jack
|
| Media Card Reader |
1x SD (Unspecified Type) (UHS-II [312 MB/s])
1x microSD (Unspecified Type) (UHS-II [312 MB/s]) |
| System Connection |
USB-C (Thunderbolt 4), USB-C (USB4)
|
Ports
| USB I/O |
2x USB-C (USB4) / Supports Video Alt Mode
1x USB-C 3.1/3.2 Gen 2 / Supports 30 W Output 2x USB-A 3.1/3.2 Gen 2 1x USB-A 3.0 / 3.1/3.2 Gen 1 |
| Network I/O |
1x RJ45 (2.5 Gb/s)
|
| Video I/O |
2x DisplayPort
2x HDMI |
| Audio I/O |
1x 1/8" / 3.5 mm Headphone/Microphone Combo Jack
|
| Media Card Reader |
1x SD (Unspecified Type) (UHS-II [312 MB/s])
1x microSD (Unspecified Type) (UHS-II [312 MB/s]) |
Host Connections
| System Connection |
USB-C (Thunderbolt 4), USB-C (USB4)
|
| Connection Type |
Detachable Cable
|
| Powered Connection |
96 W USB Power Delivery 3.0
|
General
| Number of Displays Supported |
3
|
| Maximum Resolution Supported |
7680 x 4320 at 30 Hz (Single Display)
4096 x 2160 at 60 Hz (Dual Display) 4096 x 2160 (Triple Display) |
| HDCP Support |
No
|
| OS Compatibility |
macOS 10.13 or Later
Windows 10 to 11 |
| UASP Support |
No
|
Power
| Power Source |
AC Adapter
|
| Power I/O |
Barrel Connector (Unspecified Diameter) (Input)
|
| Maximum Power Consumption |
150 W (AC Adapter)
|
| DC Input Power |
20 VDC
|
Physical
| Cable Length |
0.26' / 0.08 m
|
| Color |
Black
|
| LED Indicator |
No
|
| Lock Slot |
No
|
| Dimensions |
8.9 x 3.3 x 0.7" / 22.5 x 8.5 x 1.8 cm
|
| Weight |
0.9 lb / 0.4 kg
|
Packaging Info
| Package Weight |
2.465 lb
|
| Box Dimensions (LxWxH) |
9.5 x 5.8 x 2.7"
|
