INFINEON KITA2GTC3875VTRBTOBO1 Evaluation Board, TC387QP, TC38xQP Family, 32bit, TriCore SP005338066

KITA2GTC3875VTRBTOBO1 is a 5V standard AURIX� TC387 5V evaluation board has a TC387QP mounted directly on the board and enables customers to quickly start developing, evaluating and testing their software. The TC387 TriBoard offers a wide variety of connectors such as standard power connector, micro USB connector for ASC Interface (ASC0) and miniWiggler, RJ45 connector for Ethernet, 16-pin header for JTAG interface (OCDS), 3 x 10-pin header for DAP, DAPE and DAP-SCR (DAPE only usable on Emulation Device), 10pin (2x5) header for LIN transceiver (LIN), 2 x 10pin (2x5) header for CAN high speed transceiver (CAN0 and CAN1), 2 x 10pin (2x5) header for FlexRay� (ERAY-A and ERAY-B), four 80-pin connectors (male) + four 80-pin connectors (female) with all I/O signals, optional ETK connector, optional 2 x 6pin (IEEE1394) Socket for HSCT and optional Aurora connector (only with Emulation Device).

• Infineon�s AURIX� TC387 in LFBGA-292 package
• FlexRay�, transceivers
• High speed CAN transceivers (CAN-FD capable)
• USB to UART bridge � Ethernet Gigabit PHY
• Serial EEPROM and LIN transceiver
• Crystal 20MHz (default) or external clock
• USB miniWiggler JDS for easy debugging
• 8 low power status LEDs and 8-DIP switches for configuration
• Access to all pins of controller and 100mm x 160mm (EURO-Board)
• Reset switch, enable switch, generic switch and 4-pin DIP switch
