Infineon extends the large portfolio of the 600 V CoolMOS P7 SJ MOSFET introducing an improved version of the standard TO-247 4 pin package. The TO-247 4 pin with asymmetric leads comes along with 0.54 mm increased creepage distance between the critical leads and enables smoother wave soldering and reduced board yield loss. The additional connection to the source (Kelvin connection), that is used as a reference potential for the gate driving voltage, eliminates the effect of voltage drops over the source inductance enabling faster switching transients which results in significant efficiency improvement. This allows for higher MOSFET RDS(on) usage and BOM cost savings. CoolMOS P7 is Infineon's best balanced technology, with optimized balance of ease-of-use and highest energy efficiency Warnings Market demand for this product has caused an extension in leadtimes. Delivery dates may fluctuate. Product exempt from discounts.
Other details
| Brand |
INFINEON |
| Part Number |
IPP60R120P7XKSA1 |
| Quantity |
Each |
| Technical Data Sheet EN |
 |
