| ₹ 7494.43 includes GST and import duties. | |
| B2B customers can avail ₹ 1142.9 ITC on this product | |
| 100% Secure Payments | 100% Genuine product |
Description
Product Overview
FF150R12W2T7EB11BPSA1 is an EasyDUAL� 2B, 1200V, 150A common emitter IGBT module with TRENCHSTOP� IGBT T7, EC7, Pressfit Pin, and NTC. Suitable for motor drives, air conditioning, auxiliary inverters, servo drives and UPS systems applications.
- Electrical features: VCES = 1200V
- IC nom = 150A / ICRM = 300A
- Overload operation up to 175°C and low VCE,sat
- Mechanical features: high power density, compact design
- Al2O3 substrate with low thermal resistance
- PressFIT contact technology
- 2.5KV AC 1 minute insulation and integrated NTC temperature sensor
- Easy family with 12mm height
- Easy to design, increased power density, best cost-performance and reduced system costs
- 1.55V typ collector-emitter saturation voltage at IC = 150A, VGE = 15V, Tvj = 25°C
Product details
Other details
| Brand | INFINEON |
| Part Number | FF150R12W2T7EB11BPSA1 |
| Quantity | Each |
| Technical Data Sheet EN |  |
All product and company names are trademarks™ or registered® trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them.
Bulk Discount
| Quantity | Price |
| 2 | ₹ 7344.54 |
| 3-5 | ₹ 7269.6 |
| 5-10 | ₹ 7119.71 |
| 10+ | ₹ 6969.82 |
Bulk discount will be automatically applied during checkout based on quantity.
