INFINEON 2EP100RXTMA1 Gate Driver, EiceDRIVER, 2 Channels, Isolated, Full Bridge, GaN HEMT, IGBT, SiC MOSFET, 8 Pins 2EP100R, SP005435064

2EP100RXTMA1 is an EiceDRIVER� power full-bridge transformer driver for IGBT and SiC MOSFET gate driver supply. It is a open loop full-bridge transformer driver for designing isolated gate driver supplies for a wide variety of switch technologies (IGBTs, SiC MOSFETs, GaN HEMTs, and others). It is optimized to supply gate drivers for a variety of switches such as TRENCHSTOP� IGBTs, OptiMOS� MOSFETs, CoolMOS� superjunction MOSFETs, CoolGaN� high electron mobility transistors, and CoolSiC� MOSFETs together with EiceDRIVER� gate driver ICs, and other similar products. Potential applications include Industrial motor drives - compact, standard, premium, servo drives, solar inverters, UPS and energy storage systems, welding, commercial air-conditioning, high-voltage DC-DC converters and DC-AC inverters, isolated switch-mode power supplies, power meters.

• Wide input supply range: from 4.5V to 20V
• Supports up to 5W output power supplies
• Wide frequency range: from 65kHz to 103kHz with an internal oscillator or external clock
• Adjustable overcurrent threshold, short circuit protection for power outputs
• Overtemperature protection, ready output to indicate normal operation
• Qualified for industrial applications according to the relevant tests of JEDEC47/20/22
• Rise time is 15ns typical at VVDD = 15V, CLOAD = 1nF, VOUT from 10% to 90%
• Fall time is 15ns typical at VVDD = 15V, CLOAD = 1nF, VOUT from 90% to 10%
• PG-TSSOP-8-1 package
• Operating ambient temperature range from -40 to 125°C
