iBasso DX270 R2R Ultra Digital Audio Player (Ultra Silver)

Roll over image to zoom in

iBasso DX270 R2R Ultra Digital Audio Player (Ultra Silver)


	₹ 203340.0 includes GST and import duties.
	B2B customers can avail ₹ 31009.35 ITC on this product
	100% Secure Payments \| 100% Genuine product
	The product is eligible for Free Shipping

Brand:	iBasso
SKU:	7440865689685
MPN:	IBS-DX270-S

Share this product

iBasso DX270 R2R Ultra Overview

For audiophiles looking for a more natural take on mobile high-resolution sound, the DX270 R2R Ultra Digital Audio Player from iBasso is here to offer warmer, less processed audio through their reimagined R2R DAC. iBasso uses R2R ultra architecture and precision components such as the FPGA-Master 3.0 with four iBasso-developed digital filters, and a hybrid 8-channel, 20-bit R2R plus 4-bit String DAC. All of this is powered by a Qualcomm Snapdragon 665 SoC with five output options: 4.4mm balanced headphone, 4.4mm balanced line, 3.5mm single-ended phone, 3.5mm coaxial, and USB-C.

Reinvented R2R

iBasso has reconstructed typical a R2R implementation with a hybrid architecture of a 20-bit R2R and a 4-bit string DAC with 344 high-precision resistors. The combination is joined by an 8-channel discrete R2R and FPGA-Master 3.0 using iBasso-developed algorithms and a hardware resistor compensation network that offers 130 dB of dynamic range and a THD+N that's better than -97 dB. The components do away with zero-crossing distortion found in typical R2R in order to deliver near-perfect linearity, a wide soundstage, and delicate, natural sound.

FPGA-Master 3.0

Using 7.5 times the logic of the previous generation and dual femtosecond Accusilicon clocks, the FPGA-Master 3.0 is both an audio controller and real-time hardware calibration master. It optimizes THD+N and dynamic range by compensating for component errors, while letting you customize your sound with NOS mode and four digital filter options.

Ultra-Low Zero-Crossing Distortion

Typical of R2R DACs, zero-crossing distortion at near-zero signal levels can cause noise and muddy sound in low frequencies. iBasso achieves an ultra-low -120 dB zero-crossing distortion, subtle instrument harmonics, and nuanced vocals with the DX270 by using a fully differential architecture and precision calibration.

Additional Details

Linux-based Mango OS with Android 13
Pure sound with no Wi-Fi or Bluetooth interference and low EMI
Dual-band Wi-Fi 5 (802.11ac) and Bluetooth 5.0
5.5" touchscreen with 1080 x 2160 resolution
128GB of internal storage
microSD slot supports optional cards up to 1TB
Up to 13.5 hours of battery life

Items Included

iBasso DX270 R2R Ultra Digital Audio Player (Ultra Silver)
USB-C Cable
Coaxial Cable
Burn-In Cable
Leather Protective Case
12V AC Adapter
Screen Protector
Limited 1-Year Manufacturer Warranty

Additional Resources

No additional resources available

iBasso DX270 R2R Ultra Specs

Key Specs

Supported Formats	AAC / AIFF / ALAC / APE / DSD / DXD / FLAC / MP3 / OGG / WAV / WMA
Volume Control	Wheel
Internal Storage	128 GB

Media Support

Supported Formats

AAC / AIFF / ALAC / APE / DSD / DXD / FLAC / MP3 / OGG / WAV / WMA

Audio

Volume Control

Wheel

Connectivity

Media/Memory Card Slot	Single Slot: microSD/microSDHC/microSDXC
Internal Storage	128 GB

Power

Power I/O

1x USB-C Input

Packaging Info

Package Weight	2.035 lb
Box Dimensions (LxWxH)	8.5 x 5.3 x 4.5"

All product and company names are trademarks or registered trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them.

Quantity	Price
2	₹ 199273.2
3-5	₹ 197239.8
5-10	₹ 193173.0
10+	₹ 189106.2

Bulk discount will be automatically applied during checkout based on quantity.
