Huion Kamvas 22 Plus Overview
-
1Description
-
2Eye-Care Screen with Minimized Blue Light
-
3AG-Glass with Pen-On-Paper Drawing Experience
-
41080p Full HD Vision
-
5Pressure Levels and Improved Pen Technology
-
6System Support
Designed to be used at your workspace, the HUION Kamvas 22 Plus Pen Display allows you to draw comfortably, thanks to its mountable stand. Featuring a 22" display with an 18.77 x 10.56" active area, it's built with an IPS panel, which provides users with vivid colors and wide 178° viewing angles. Thanks to its quantum dot technology, this screen features a 140% sRGB color gamut and can also minimize the effects of blue light. Moreover, the display is fully laminated to minimize cursor movement while the chemically etched glass can lighten the glare and provide a pen-on-paper drawing experience. The Kamvas Plus 22 is compatible with Mac, Windows, and Android devices and comes with a stand and stylus to help you get started.
Eye-Care Screen with Minimized Blue Light
With the application of quantum dot technology, this display not only enables a 140% sRGB color gamut and vivid color presentation, but also minimizes the effects of blue light.
AG-Glass with Pen-On-Paper Drawing Experience
A fully laminated screen can minimize cursor movement, and a chemically etched glass can lighten the glare and provide a pen-on-paper drawing experience.
1080p Full HD Vision
The display features a Full HD 1920 x 1080 resolution and a 16:9 aspect ratio. Its IPS panel provides 178° wide viewing angles.
Pressure Levels and Improved Pen Technology
The included PW517 digital pen features battery-free EMR technology. It also supports 8192 pressure levels of sensitivity.
System Support
Windows (7 and later), mac OS (10.12 and later) and Android (USB3.1 GEN1 & DP1.2) are supported, compatible with all major mainstream painting and design software (such as PS, SAI, AI, CDR).
![]()
UPC: 694026042351
In the Box
- Huion Kamvas 22 Plus Pen Display
- PW517 Pen
- PH05A Pen Holder with PN05A (10 Points) and Point Clip
- 3-in-1 Cable
- USB Type-C Cable
- Power Cable
- Power Adapter
- Mountable Stand
- Glove
- Cleaning Cloth
- Limited 1-Year Warranty
Table of Contents
- Description
- Eye-Care Screen with Minimized Blue Light
- AG-Glass with Pen-On-Paper Drawing Experience
- 1080p Full HD Vision
- Pressure Levels and Improved Pen Technology
- System Support
Huion Kamvas 22 Plus Specs
Display
| Panel Type |
IPS |
| Size |
22" |
| Aspect Ratio |
16:9 |
| Resolution |
1920 x 1080 |
| Video Ports |
1 x USB Type-C |
| Contrast Ratio |
1200:1 |
| Color Gamut |
140% sRGB |
| Brightness |
250 cd/m² |
| Response Time |
14 ms |
| Display Colors |
16.7 Million |
| Viewing Angle (H x V) |
178 x 178° |
Tablet
| Active Area |
18.77 x 10.56" / 476.64 x 268.11 mm |
| Number of Buttons |
5 |
| Buttons Customizable |
No |
| Connectivity Ports |
1 x USB Type-A |
| USB Type-C Ports |
1 x Unspecified USB |
| Connectivity Cable |
USB Type-C |
| Dimensions (W x H x D) |
21.5 x 12.7 x 1.1" / 546 x 323 x 26.7 mm |
Stylus
| Pressure Levels |
8192 |
| Tilt |
60° |
| Report Rate |
220 pps |
| Resolution |
5080 lpi |
| Stylus Accuracy |
±11.8 mil / 0.3 mm |
| Technology |
Electromagnetic Resonance (EMR) |
General
| Operating System Support |
Android, Windows, macOS/OS X |
| Weight |
8.6 lb / 3.9 kg |
| Warranty Length |
Limited 1-Year Warranty |
Packaging Info
| Package Weight |
15 lb |
| Box Dimensions (LxWxH) |
25 x 17.5 x 6.5" |
