Description
Honeywell 3104-55-12 Overview
The 500' long clear Genesis Series 22 AWG Unshielded Untwisted Multi-Conductor Cable with 4 Unpaired Conductors from Honeywell comes in a pull box packaging. The untwisted cable offers a gauge size of 22 AWG. It is unshielded and features a general-purpose jacketing material. Applications for this cable include control cables (Lutron systems and Crestron systems), alarms, intercoms, speakers, and other low-voltage circuits that are power limited.
Countdown or sequential footage markings
Room and zone markings
CMP, CL2P, C(UL), FT6 listed
UL Standards 13, & 444; NEC Articles 725 & 800
Flame Rating: UL 910, NFPA 262, CSA FT6
UPC: 619172012980
In the Box
- Honeywell Genesis Series 22 AWG Unshielded Untwisted Multi-Conductor Cable with 4 Unpaired Conductors (Clear, 500' Pull Box)
- Limited 3-Year Warranty on Parts & Labor
Honeywell 3104-55-12 Specs
| Gauge |
22 AWG
|
| Conductors |
4 x 7/.0096 bare copper
|
| Insulation |
Plenum PVC
Nominal Thickness: 0.007" (0.178 mm) Diameter: 0.043" (1.092 mm) Colors: Black, white, red, and green |
| Jacket |
Plenum, low-smoke PVC
Nominal Thickness: 0.015" (0.381 mm) |
| Lay Length |
Nominal: 2.5" (63.5 mm)
|
| DC Resistance |
16.5 ?/m at 20°C
|
| Nominal Impedance |
85 ?
|
| Pulling Tension |
Maximum: 7.0 lb (3.2 kg)
Recommended: 5.25 lb (2.38 kg) |
| Temperature Rating |
-4 to 140°F (-20 to 60°C)
|
| Operating Voltage |
Maximum: 300 V
|
| Outer Diameter |
Nominal: 0.136" (3.454 mm)
|
| Length |
500.0' (152.4 m)
|
| Weight |
17.0 lb per MFT (7.7 kg per MFT)
|
Packaging Info
| Package Weight |
8.4 lb
|
| Box Dimensions (LxWxH) |
10.236 x 10.236 x 6.378"
|
